Phoenix Contact 1582211
The picture is for reference only, please refer to the product specification
- 1582211
- Phoenix Contact
- CONN INLINE BLACK,3+PE-PO
- Circular Connectors
- 1582211 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 14109
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is 1582211
Phoenix Contact Part Number 1582211（Circular Connectors）, developed and manufactured by Phoenix Contact, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
1582211 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
1582211 Specifications
- Part Number1582211
- CategoryCircular Connectors
- ManufacturerPhoenix Contact
- DescriptionCONN INLINE BLACK,3+PE-PO
- Package-
- SeriesQPD
- Mounting TypeFree Hanging (In-Line)
- TerminationIDC
- Ingress ProtectionIP68/69K - Dust Tight, Water Resistant, Waterproof
- Current Rating20A
- Voltage - Rated630V
- Contact FinishSilver
- OrientationKeyed
- Number of Positions4 (3 + PE)
- Connector TypeDistributor
- Fastening TypeThreaded
- Shell Material, FinishPolyamide (PA), Nylon
Application of 1582211
1582211 Datasheet
1582211 Datasheet , QPD,Free Hanging (In-Line),IDC,IP68/69K - Dust Tight, Water Resistant, Waterproof,20A,630V,Silver,Keyed,4 (3 + PE),Distributor,Threaded,Polyamide (PA), Nylon
1582211 Classification
Circular Connectors
FAQ about Circular Connectors
-
1. What is a circular connector
A circular connector is a cylindrical electronic connector with a circular mating surface. It belongs to the fifth category of the interconnection classification and is mainly used for interconnection between devices. The design of circular connectors includes many types, such as low-frequency circular connectors, RF coaxial connectors and audio connectors, etc., with a wide operating temperature range from -55℃ to +150℃.
-
2. How to get pins out of circular connector
Use professional tools: For some connectors, professional tools may be required to safely remove pins. For example, the small two-petal needle remover mentioned may not be very easy to use, but if there is no other better method, you can try to use it. If the connector is damaged or the repair cost is too high, consider replacing a new connector.
-
3. How to solder a circular connector
1. Remove the insulator, prepare the soldering iron and needle-nosed pliers or tweezers;
2. Place the blade of the soldering iron tip close to the solder joint, and keep the soldering iron at an angle of about 60° to the horizontal plane so that the molten tin can flow smoothly from the soldering iron tip to the solder joint. The time the soldering iron tip stays at the solder joint should be controlled to 1-2 seconds;
3. Make sure that the insulator is not burned, the tin on the solder joint is smooth, burr-free, and there is no cold solder joint, and the definition of the solder wire meets the requirements of the drawing. -
4. What is the circular connector called
Circular connectors are also called circular electrical connectors, sealed circular connectors, aviation plugs, waterproof connectors, etc. Different names for different usage environments: waterproof connectors, waterproof plugs; sealed circular connectors, etc.
