Aries Electronics C9116-00
The picture is for reference only, please refer to the product specification
- C9116-00
- Aries Electronics
- CONN IC DIP SOCKET 16POS GOLD
- Sockets for ICs, Transistors
- C9116-00 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 4103
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is C9116-00
Aries Electronics Part Number C9116-00（Sockets for ICs, Transistors）, developed and manufactured by Aries Electronics, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
C9116-00 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
C9116-00 Specifications
- Part NumberC9116-00
- CategorySockets for ICs, Transistors
- ManufacturerAries Electronics
- DescriptionCONN IC DIP SOCKET 16POS GOLD
- Package-
- SeriesEdge-Grip?, C91
- TypeDIP, 0.3" (7.62mm) Row Spacing
- FeaturesClosed Frame
- Operating Temperature-55°C ~ 125°C
- Mounting TypeThrough Hole
- TerminationWire Wrap
- Housing MaterialPolyamide (PA46), Nylon 4/6, Glass Filled
- Pitch - Mating0.100" (2.54mm)
- Contact Finish - MatingGold
- Contact Finish - PostGold
- Contact Finish Thickness - Mating10µin (0.25µm)
- Number of Positions or Pins (Grid)16 (2 x 8)
- Contact Material - MatingPhosphor Bronze
- Pitch - Post0.100" (2.54mm)
- Contact Finish Thickness - Post10µin (0.25µm)
- Contact Material - PostPhosphor Bronze
