CMDD4448 TR

Central Semiconductor Corp CMDD4448 TR

The picture is for reference only, please refer to the product specification

  • CMDD4448 TR
  • Central Semiconductor Corp
  • DIODE GEN PURP 75V 250MA SOD323
  • Diodes - Rectifiers - Single
  • CMDD4448 TR Datasheet
  • SC-76, SOD-323
  • SC-76, SOD-323
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 2061
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is CMDD4448 TR

Central Semiconductor Corp Part Number CMDD4448 TR（Diodes - Rectifiers - Single）, developed and manufactured by Central Semiconductor Corp, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

CMDD4448 TR is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

CMDD4448 TR Specifications

  • Part NumberCMDD4448 TR
  • CategoryDiodes - Rectifiers - Single
  • ManufacturerCentral Semiconductor Corp
  • DescriptionDIODE GEN PURP 75V 250MA SOD323
  • PackageSC-76, SOD-323
  • Series-
  • Mounting TypeSurface Mount
  • Package / CaseSC-76, SOD-323
  • Supplier Device PackageSOD-323
  • Diode TypeStandard
  • Current - Average Rectified (Io)250mA
  • Voltage - Forward (Vf) (Max) @ If1V @ 100mA
  • Current - Reverse Leakage @ Vr25nA @ 20V
  • Capacitance @ Vr, F4pF @ 0V, 1MHz
  • Voltage - DC Reverse (Vr) (Max)75V
  • SpeedFast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr)4ns
  • Operating Temperature - Junction-65°C ~ 175°C

Application of CMDD4448 TR

Rectifiers are used in an extremely wide range of applications, covering almost all situations where DC power is required. In terms of power supply equipment, rectifiers are widely used in power transformers, switching power supplies, etc., to provide stable DC power for various electronic equipment. In the field of lighting, with the popularity of new light sources such as LED, rectifier-single also plays an important role, it can convert alternating current into direct current to drive LED lights and other light-emitting devices, to achieve energy-efficient lighting effects. In addition, in many fields such as industrial automation, communication equipment, automotive electronics, medical equipment, rectifiers also play an irreplaceable role. Especially in the field of industrial automation, rectifiers - provide a stable DC power supply for motors, frequency converters and other equipment, ensuring the stable operation of the production line and efficient production.

CMDD4448 TR Datasheet

CMDD4448 TR Datasheet , SC-76, SOD-323,Surface Mount,SC-76, SOD-323,SOD-323,Standard,250mA,1V @ 100mA,25nA @ 20V,4pF @ 0V, 1MHz,75V,Fast Recovery =< 500ns, > 200mA (Io),4ns,-65°C ~ 175°C

CMDD4448 TR Classification

Diodes - Rectifiers - Single

Rectifiers - Single refers to a standalone rectifier device, which usually contains one or several rectifying elements (such as diodes), and its core function is to convert alternating current (AC) to direct current (DC). Specifically, it takes advantage of the unidirectional conductivity of semiconductor diodes, allowing current to pass in only one direction, thus enabling the conversion from fluctuating alternating current to stable direct current.

FAQ about Diodes - Rectifiers - Single

  • 1. What is a single rectifier diode?

    A single rectifier diode is an electronic component used to convert alternating current (AC) to direct current (DC), typically used in power supplies, chargers, and other circuits that require DC power.

  • 2. What is a fast recovery diode?

    Fast recovery diode is a special type of rectifier diode with a short reverse recovery time, suitable for high-frequency power supplies and switch mode power supplies (SMPS) applications, reducing switching losses.

  • 3. What are the packaging types of rectifier diodes?

    There are various packaging types for rectifier diodes, including axial pin packaging (such as DO-41), surface mount packaging (such as SMA, SMB), and high-power packaging (such as TO-220). When selecting, the appropriate packaging should be chosen based on the application's heat dissipation requirements and installation method.
