LM3886TF

National Semiconductor LM3886TF

The picture is for reference only, please refer to the product specification

  • LM3886TF
  • National Semiconductor
  • LM3886 68W, 1 CH, 20-94V SUPPLY
  • Linear - Amplifiers - Audio
  • LM3886TF Datasheet
  • TO-220-11 Isolated Tab, Formed Leads
  • Bulk
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 1215
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is LM3886TF

National Semiconductor Part Number LM3886TF（Linear - Amplifiers - Audio）, developed and manufactured by National Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

LM3886TF is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

LM3886TF Specifications

  • Part NumberLM3886TF
  • CategoryLinear - Amplifiers - Audio
  • ManufacturerNational Semiconductor
  • DescriptionLM3886 68W, 1 CH, 20-94V SUPPLY
  • PackageBulk
  • SeriesOverture™
  • TypeClass AB
  • FeaturesMute, Short-Circuit and Thermal Protection
  • Voltage - Supply20V ~ 84V, ±10V ~ 42V
  • Operating Temperature-20°C ~ 85°C (TA)
  • Mounting TypeThrough Hole
  • Package / CaseTO-220-11 Isolated Tab, Formed Leads
  • Supplier Device PackageTO-220-11 Isolated
  • Output Type1-Channel (Mono)
  • Max Output Power x Channels @ Load68W x 1 @ 4Ohm

Application of LM3886TF

Amplifiers - Audio application field is very wide, almost covers all need amplification. In a personal sound system, it is a bridge between the sound source and the speaker, bringing a more shocking and clear hearing experience to the user. In the home theater system, the audio amplifier is responsible for amplifying the sound signal in the movie, creating an immersive sound environment and enhancing the immersion of the movie. In addition, in many fields such as car audio, stage audio, and public address systems, audio amplifiers also play an irreplaceable role.

LM3886TF Datasheet

LM3886TF Datasheet , Bulk,Overture™,Class AB,Mute, Short-Circuit and Thermal Protection,20V ~ 84V, ±10V ~ 42V,-20°C ~ 85°C (TA),Through Hole,TO-220-11 Isolated Tab, Formed Leads,TO-220-11 Isolated,1-Channel (Mono),68W x 1 @

LM3886TF Classification

Linear - Amplifiers - Audio

Amplifiers - Audio is a kind of can receive weak electrical signals, and the power amplifier to the level of large enough so that the driving load (usually the speaker) of the electronic device. This process involves the amplification of voltage and current to ensure that the output signal can effectively excite the speaker to vibrate and produce sound. In short, it is a device capable of significantly enhancing the power of the audio signal, which is designed to amplify the weak audio signal enough to drive output devices such as speakers and headphones, thereby significantly improving the loudness and clarity of the sound.

FAQ about Linear - Amplifiers - Audio

  • 1. What is an audio amplifier and what does it do?

    An audio amplifier is a device that amplifies an audio signal, such as music or speech, to a higher voltage or current level to drive speakers or headphones, ensuring that the sound remains clear and accurate when played at higher volumes.

  • 2. What is a Class D audio amplifier and what are its advantages?

    Class D audio amplifiers work through Pulse Width Modulation (PWM) technology and have extremely high efficiency (typically up to 90% or higher), making them suitable for use in portable audio equipment or high-efficiency sound systems. It generates less heat because it reduces energy consumption.

  • 3. Does the audio amplifier need to match the impedance of the speakers?

    Yes, the output impedance of the audio amplifier should match the impedance of the speaker. Typically speakers have an impedance of 4Ω, 8Ω or 16Ω. Matching the impedance ensures that the amplifier delivers maximum power and the best sound quality from the speaker.
