KYOCERA AVX RP42525R0100GTTR
The picture is for reference only, please refer to the product specification
- RP42525R0100GTTR
- KYOCERA AVX
- RES SMD 100 OHM 2% 20W 2525
- Chip Resistor - Surface Mount
- RP42525R0100GTTR Datasheet
- 2525 (6464 Metric)
- 2525 (6464 Metric)
-
Lead free / RoHS Compliant - 3913
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is RP42525R0100GTTR
KYOCERA AVX Part Number RP42525R0100GTTR（Chip Resistor - Surface Mount）, developed and manufactured by KYOCERA AVX, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
RP42525R0100GTTR is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
RP42525R0100GTTR Specifications
- Part NumberRP42525R0100GTTR
- CategoryChip Resistor - Surface Mount
- ManufacturerKYOCERA AVX
- DescriptionRES SMD 100 OHM 2% 20W 2525
- Package2525 (6464 Metric)
- SeriesRP4
- Operating Temperature-55°C ~ 150°C
- Package / Case2525 (6464 Metric)
- Supplier Device Package2525
- Tolerance±2%
- Temperature Coefficient150ppm/°C
- Size / Dimension0.245" L x 0.245" W (6.22mm x 6.22mm)
- Power (Watts)20W
- Height - Seated (Max)0.045" (1.15mm)
- Resistance100 Ohms
- CompositionThin Film
- Number of Terminations2
Application of RP42525R0100GTTR
RP42525R0100GTTR Datasheet
RP42525R0100GTTR Datasheet , 2525 (6464 Metric),RP4,-55°C ~ 150°C,2525 (6464 Metric),2525,±2%,150ppm/°C,0.245" L x 0.245" W (6.22mm x 6.22mm),20W,0.045" (1.15mm),100 Ohms,Thin Film,2
RP42525R0100GTTR Classification
Chip Resistor - Surface Mount
FAQ about Chip Resistor - Surface Mount
-
1. How to choose Chip Resistor?
The application of surface mount technology (SMT) has been very common, and the proportion of electronic products assembled by SMT has exceeded 90%. my country began to introduce SMT technology in the 1980s. With the development of small SMT production equipment, the application scope of SMT is further expanding. Aviation, aerospace, instrumentation, machine tools and other fields are also using SMT to produce various small-volume electronic products or components.
In recent years, in addition to electronic product developers using SMT devices to develop new products, maintenance personnel have also begun to repair electronic products assembled by SMT technology in large quantities.
The models of SMT resistors are not uniform, and are set by each manufacturer, and the models are particularly long (consisting of more than a dozen English letters and numbers). If you can correctly propose various parameters and specifications of SMT resistors when purchasing, you can easily purchase (or order) the required resistors.
There are 5 parameters for SMT resistors, namely size, resistance, tolerance, temperature coefficient and packaging.
1. Size series SMT resistor series generally have 7 sizes, represented by two size codes. One size code is a 4-digit EIA (Electronics Industry Association) code, the first two digits and the last two digits represent the length and width of the resistor, in inches. The other is a metric code, also represented by 4 digits, in millimeters. Resistors of different sizes have different power ratings. Table 1 lists the codes and power ratings of these seven resistor sizes.
2. Resistance series The nominal resistance is determined by series. Each series is divided by the tolerance of the resistor (the smaller the tolerance, the more resistance divisions), among which the most commonly used is E-24 (the tolerance of the resistance value is ±5%), as shown in Table 2.
The resistance value is indicated by three digits on the surface of the chip resistor, of which the first and second digits are valid numbers, and the third digit indicates the number of zeros. When there is a decimal point, it is indicated by "R" and occupies one valid digit. The nominal resistance code representation method is shown in Table 3.
3. Tolerance The tolerance of chip resistors (carbon film resistors) has 4 levels, namely F level, ±1%; G level, ±2%; J level, ±5%; K level, ±10%.
4. Temperature coefficient The temperature coefficient of chip resistors has 2 levels, namely W level, ±200ppm/℃; X level, ±100ppm/℃. Only resistors with tolerance level F use level x, and resistors with tolerance levels of other levels are generally level w.
5. There are two main types of packaging: bulk and tape and roll.
The operating temperature range of chip resistors is -55--+125℃, and the maximum operating voltage is related to the size: 0201 is the lowest, 0402 and 0603 are 50V, 0805 is 150V, and other sizes are 200V.
6. The numbers on the surface of the chip resistors are arranged horizontally, and are specified to be represented by three digits, of which the first two are valid digits, and the third is the exponent of 10, in units of ohms. For example: 473 means 47×103=47 kΩ. If the second character on the surface of the resistor used to indicate the resistance value is the letter R, it represents a decimal point, for example: 5R1 means the resistance value is 5.1Ω. -
2. Resistance value representation method
In the digital identification of chip resistors, the first three digits are usually used to indicate the resistance value. These digits are interpreted in decimal, such as "100" means the resistance value is 100 ohms. In some cases, if the resistor value is large, "R" may be used to indicate the decimal point position, such as "1R0" for a resistor value of 1.0 ohm.
-
3. Resistor digital identification interpretation example
To better understand the interpretation method of chip resistor digital identification, let's look at an example. Assuming that the digital identification on a chip resistor is "1001", what is the resistance value of this resistor? What is the accuracy?
First, we interpret the first three digits "100", indicating that the resistance value is 100 ohms. Next, we look at the last digit "1", which indicates that the tolerance accuracy of the resistor is 1%. Therefore, the resistance of this chip resistor is 100 ohms and the tolerance accuracy is ±1%.
