TBS22J-TP

Micro Commercial Co TBS22J-TP

The picture is for reference only, please refer to the product specification

  • TBS22J-TP
  • Micro Commercial Co
  • BRIDGE RECT 1P 600V 2.2A 4TBS
  • Diodes - Bridge Rectifiers
  • TBS22J-TP Datasheet
  • 4-SMD, Flat Leads
  • Cut Tape (CT)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 3687
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is TBS22J-TP

Micro Commercial Co Part Number TBS22J-TP（Diodes - Bridge Rectifiers）, developed and manufactured by Micro Commercial Co, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

TBS22J-TP is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

TBS22J-TP Specifications

  • Part NumberTBS22J-TP
  • CategoryDiodes - Bridge Rectifiers
  • ManufacturerMicro Commercial Co
  • DescriptionBRIDGE RECT 1P 600V 2.2A 4TBS
  • PackageCut Tape (CT)
  • Series-
  • Operating Temperature-55°C ~ 150°C (TJ)
  • Mounting TypeSurface Mount
  • Package / Case4-SMD, Flat Leads
  • Supplier Device Package4-TBS
  • TechnologyStandard
  • Diode TypeSingle Phase
  • Voltage - Peak Reverse (Max)600 V
  • Current - Average Rectified (Io)2.2 A
  • Voltage - Forward (Vf) (Max) @ If1.1 V @ 2 A
  • Current - Reverse Leakage @ Vr5 µA @ 600 V

Application of TBS22J-TP

Diodes - Bridge Rectifiers are used in a wide range of applications. In consumer electronics, such as televisions, computer power adapters, and personal electronic device chargers, bridge rectifiers are an integral part. In industrial applications, it is used in various control systems, drive systems, and automation equipment to provide reliable DC power. In addition, with the development of renewable energy technologies, such as solar photovoltaic systems and wind power systems, bridge rectifiers are also used to convert the output of these systems into a form of electricity that can be used directly by the grid or load. All in all, where there is a demand for stable and efficient DC power, bridge rectifiers can be found.

TBS22J-TP Datasheet

TBS22J-TP Datasheet , Cut Tape (CT),-55°C ~ 150°C (TJ),Surface Mount,4-SMD, Flat Leads,4-TBS,Standard,Single Phase,600 V,2.2 A,1.1 V @ 2 A,5 µA @ 600 V

TBS22J-TP Classification

Diodes - Bridge Rectifiers

Bridge Rectifiers are circuit devices consisting of four diodes connected in a specific manner (usually in the shape of an "H" or "bridge"), whose main function is to convert alternating current (AC) to direct current (DC). This conversion process takes advantage of the diode's unidirectional conductivity, which allows the current to pass in only one direction. In a bridge rectifier, each diode is responsible for conducting the AC for one and a half cycles, thus ensuring that no matter how the polarity of the AC changes, there is a continuous current passing through the load, creating a continuous DC output.

FAQ about Diodes - Bridge Rectifiers

  • 1. What is a bridge rectifier?

    A bridge rectifier is a circuit composed of four diodes used to convert alternating current (AC) to direct current (DC). It is a common type of rectifier circuit widely used in devices such as power supplies and chargers.

  • 2. What are the common applications of bridge rectifiers?

    Bridge rectifiers are widely used in power supplies, chargers, household appliances, power tools, lighting systems, and various electronic devices to provide stable DC power.

  • 3. How to reduce the ripple voltage of bridge rectifier?

    Ripple voltage can be reduced by adding filtering capacitors or using more complex filters (such as inductive filters) in the rectifier circuit, resulting in a smoother DC output.
