TLC073AIN

Texas Instruments TLC073AIN

The picture is for reference only, please refer to the product specification

  • TLC073AIN
  • Texas Instruments
  • OPERATIONAL AMPLIFIER
  • Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
  • TLC073AIN Datasheet
  • 14-DIP (0.300\", 7.62mm)
  • Tube
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 1845
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is TLC073AIN

Texas Instruments Part Number TLC073AIN（Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps）, developed and manufactured by Texas Instruments, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

TLC073AIN is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

TLC073AIN Specifications

  • Part NumberTLC073AIN
  • CategoryLinear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
  • ManufacturerTexas Instruments
  • DescriptionOPERATIONAL AMPLIFIER
  • PackageTube
  • SeriesAutomotive, AEC-Q100
  • Operating Temperature-40°C ~ 125°C
  • Mounting TypeThrough Hole
  • Package / Case14-DIP (0.300\", 7.62mm)
  • Supplier Device Package14-PDIP
  • Current - Supply2.1mA (x2 Channels)
  • Output Type-
  • Number of Circuits2
  • Voltage - Supply, Single/Dual (±)4.5V ~ 16V, ±2.25V ~ 8V
  • Current - Output / Channel57 mA
  • -3db Bandwidth-
  • Amplifier TypeCMOS
  • Current - Input Bias1.5 pA
  • Voltage - Input Offset390 µV
  • Slew Rate16V/µs
  • Gain Bandwidth Product10 MHz

Application of TLC073AIN

Instrumentation Amplifier is commonly used in medical instruments, industrial sensors, precision measuring equipment and other applications. Its high common-mode rejection ratio and low noise characteristics make it possible to accurately capture and amplify weak signals in complex environments, improving the measurement accuracy. Operational Amplifier (Op-Amp) Operational amplifier is widely used in analog signal processing, signal generation, filter design, automatic control and other fields. Its flexibility and powerful computing power provide engineers with a broad design space, making the realization of complex circuits possible. Buffer Amplifier is widely used in audio amplification, video transmission, data acquisition and other systems, effectively improving the stability and reliability of signal transmission.

TLC073AIN Datasheet

TLC073AIN Datasheet , Tube,Automotive, AEC-Q100,-40°C ~ 125°C,Through Hole,14-DIP (0.300\", 7.62mm),14-PDIP,2.1mA (x2 Channels),2,4.5V ~ 16V, ±2.25V ~ 8V,57 mA,CMOS,1.5 pA,390 µV,16V/µs,10 MHz

TLC073AIN Classification

Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

Instrumentation amplifiers are designed for high precision measurements. It can effectively amplify weak differential signals (that is, two similar but slightly different signals), while suppressing common mode noise (that is, noise shared by two signals), thus ensuring the purity and accuracy of the signal.Operational Amplifier (Op-Amp) is a high-gain DC amplifier with differential input and single-ended output. Operational amplifiers can not only be used as amplifiers, but also realize mathematical operations such as addition, subtraction, integration, and differentiation through external circuit configuration.Buffer Amplifier is a special amplifier configuration that aims to keep the voltage of the input signal constant while providing enough driving capacity to support the load. It is usually implemented based on an operational amplifier.

FAQ about Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

  • 1. What is Common Mode Rejection Ratio (CMRR) and why is it important for instrumentation amplifiers?

    CMRR indicates an instrumentation amplifier's ability to suppress common mode signals, with higher values being better. A high CMRR is especially important in noisy environments to ensure that the amplifier primarily amplifies differential signals and is not affected by common mode interference.

  • 2. What is a Buffer Amp and what is its function?

    A Buffer Amp is an amplifier with a unit gain that is mainly used in voltage follower circuits to provide a high input impedance and a low output impedance to isolate the signal source from the load and prevent signal distortion or attenuation.

  • 3. What are the application scenarios of buffer amplifiers?

    Buffer amplifiers are commonly used in signal isolation, impedance matching, voltage follower and power amplification scenarios, and are suitable for protecting weak signal sources from load effects in signal processing chains.
