Texas Instruments UCC21521ADW
- UCC21521ADW
- Texas Instruments
- OPTOISO 5.7KV GATE DRVR 16SOIC
- Isolators - Gate Drivers
- UCC21521ADW Datasheet
- 16-SOIC (0.295", 7.50mm Width)
- 16-SOIC (0.295", 7.50mm Width)
- Lead free / RoHS Compliant
- 783
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
Part Number UCC21521ADW |
Category Isolators - Gate Drivers |
Manufacturer Texas Instruments |
Description OPTOISO 5.7KV GATE DRVR 16SOIC |
Package 16-SOIC (0.295", 7.50mm Width) |
Series - |
Voltage - Supply 6.5 V ~ 25 V |
Operating Temperature -40°C ~ 125°C |
Mounting Type Surface Mount |
Package / Case 16-SOIC (0.295", 7.50mm Width) |
Supplier Device Package 16-SOIC |
Number of Channels 2 |
Technology Capacitive Coupling |
Voltage - Isolation 5700Vrms |
Approvals CQC, CSA, UR, VDE |
Common Mode Transient Immunity (Min) 100V/ns |
Propagation Delay tpLH / tpHL (Max) 30ns, 30ns |
Pulse Width Distortion (Max) 5ns |
Rise / Fall Time (Typ) 6ns, 7ns |
Current - Output High, Low 4A, 6A |
Package_case 16-SOIC (0.295", 7.50mm Width) |
