VS-8TQ100STRLPBF

Vishay Semiconductor - Diodes Division VS-8TQ100STRLPBF

The picture is for reference only, please refer to the product specification

  • VS-8TQ100STRLPBF
  • Vishay Semiconductor - Diodes Division
  • DIODE SCHOTTKY 100V 8A D2PAK
  • Diodes - Rectifiers - Single
  • VS-8TQ100STRLPBF Datasheet
  • TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Tape & Reel (TR)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 2889
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is VS-8TQ100STRLPBF

Vishay Semiconductor - Diodes Division Part Number VS-8TQ100STRLPBF（Diodes - Rectifiers - Single）, developed and manufactured by Vishay Semiconductor - Diodes Division, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

VS-8TQ100STRLPBF is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

VS-8TQ100STRLPBF Specifications

  • Part NumberVS-8TQ100STRLPBF
  • CategoryDiodes - Rectifiers - Single
  • ManufacturerVishay Semiconductor - Diodes Division
  • DescriptionDIODE SCHOTTKY 100V 8A D2PAK
  • PackageTape & Reel (TR)
  • Series-
  • Mounting TypeSurface Mount
  • Package / CaseTO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Supplier Device PackageTO-263AB (D²PAK)
  • Diode TypeSchottky
  • Current - Average Rectified (Io)8A
  • Voltage - Forward (Vf) (Max) @ If720 mV @ 8 A
  • Current - Reverse Leakage @ Vr550 µA @ 100 V
  • Capacitance @ Vr, F500pF @ 5V, 1MHz
  • Voltage - DC Reverse (Vr) (Max)100 V
  • SpeedFast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr)-
  • Operating Temperature - Junction-55°C ~ 175°C

Application of VS-8TQ100STRLPBF

Rectifiers are used in an extremely wide range of applications, covering almost all situations where DC power is required. In terms of power supply equipment, rectifiers are widely used in power transformers, switching power supplies, etc., to provide stable DC power for various electronic equipment. In the field of lighting, with the popularity of new light sources such as LED, rectifier-single also plays an important role, it can convert alternating current into direct current to drive LED lights and other light-emitting devices, to achieve energy-efficient lighting effects. In addition, in many fields such as industrial automation, communication equipment, automotive electronics, medical equipment, rectifiers also play an irreplaceable role. Especially in the field of industrial automation, rectifiers - provide a stable DC power supply for motors, frequency converters and other equipment, ensuring the stable operation of the production line and efficient production.

VS-8TQ100STRLPBF Datasheet

VS-8TQ100STRLPBF Datasheet , Tape & Reel (TR),Surface Mount,TO-263-3, D²Pak (2 Leads + Tab), TO-263AB,TO-263AB (D²PAK),Schottky,8A,720 mV @ 8 A,550 µA @ 100 V,500pF @ 5V, 1MHz,100 V,Fast Recovery =< 500ns, > 200mA (Io),-55°C ~ 175°C

VS-8TQ100STRLPBF Classification

Diodes - Rectifiers - Single

Rectifiers - Single refers to a standalone rectifier device, which usually contains one or several rectifying elements (such as diodes), and its core function is to convert alternating current (AC) to direct current (DC). Specifically, it takes advantage of the unidirectional conductivity of semiconductor diodes, allowing current to pass in only one direction, thus enabling the conversion from fluctuating alternating current to stable direct current.

FAQ about Diodes - Rectifiers - Single

  • 1. How to identify the polarity of a single rectifier diode?

    Rectifying diodes usually have polarity markings, with the positive (anode) of the diode being &quot;+&quot; and the negative (cathode) being &quot;-&quot;. On the packaging of diodes, there is usually a circular mark on the cathode side indicating the direction of the diode.

  • 2. How to determine if the rectifier diode is damaged?

    Use a multimeter to measure the forward and reverse resistance of a diode. If the diode exhibits low impedance or high impedance in both directions, it may have been damaged. Under normal circumstances, there should be low impedance when conducting in the forward direction, and high impedance when conducting in the reverse direction.

  • 3. What are the packaging types of rectifier diodes?

    There are various packaging types for rectifier diodes, including axial pin packaging (such as DO-41), surface mount packaging (such as SMA, SMB), and high-power packaging (such as TO-220). When selecting, the appropriate packaging should be chosen based on the application's heat dissipation requirements and installation method.
