FAN7388MX

Fairchild Semiconductor FAN7388MX

The picture is for reference only, please refer to the product specification

  • FAN7388MX
  • Fairchild Semiconductor
  • IC GATE DRIVER HALF BRIDG 20SOIC
  • PMIC - Gate Drivers
  • FAN7388MX Datasheet
  • 20-SOIC (0.295", 7.50mm Width)
  • 20-SOIC (0.295", 7.50mm Width)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 1264
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is FAN7388MX

Fairchild Semiconductor Part Number FAN7388MX（PMIC - Gate Drivers）, developed and manufactured by Fairchild Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

FAN7388MX is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

FAN7388MX Specifications

  • Part NumberFAN7388MX
  • CategoryPMIC - Gate Drivers
  • ManufacturerFairchild Semiconductor
  • DescriptionIC GATE DRIVER HALF BRIDG 20SOIC
  • Package20-SOIC (0.295", 7.50mm Width)
  • Series-
  • Voltage - Supply10 V ~ 20 V
  • Operating Temperature-40°C ~ 150°C (TJ)
  • Mounting TypeSurface Mount
  • Package / Case20-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package20-SOIC
  • Input TypeNon-Inverting
  • Channel Type3-Phase
  • Rise / Fall Time (Typ)50ns, 30ns
  • Driven ConfigurationHalf-Bridge
  • Number of Drivers6
  • Gate TypeIGBT, N-Channel MOSFET
  • Logic Voltage - VIL, VIH1V, 2.5V
  • Current - Peak Output (Source, Sink)350mA, 650mA
  • High Side Voltage - Max (Bootstrap)600V

Application of FAN7388MX

Gate Drivers have been widely used in various fields of power electronics technology. In the motor control system, the gate driver is used to drive the MOSFET or IGBT switching components of the inverter to achieve accurate control and efficient operation of the motor, which is widely used in the fields of electric vehicles, industrial automation equipment and household appliances. In power inverters, the gate driver is responsible for converting DC power to AC power to meet the needs of various loads, commonly seen in solar photovoltaic systems, wind power systems and uninterruptible power supplies (UPS). In addition, gate drivers also play an important role in many fields such as switching power supplies, AC frequency converters, and power electronic converters.

FAN7388MX Datasheet

FAN7388MX Datasheet , 20-SOIC (0.295", 7.50mm Width),10 V ~ 20 V,-40°C ~ 150°C (TJ),Surface Mount,20-SOIC (0.295", 7.50mm Width),20-SOIC,Non-Inverting,3-Phase,50ns, 30ns,Half-Bridge,6,IGBT, N-Channel MOSFET,1V, 2.5V,350mA

FAN7388MX Classification

PMIC - Gate Drivers

Gate Drivers are circuits specifically designed to enhance and control the gate signals of a MOSFET or IGBT. It receives low-voltage and low-current signals from the controller and converts them into high-voltage and high-current pulse signals that directly act on the gate of the MOSFET or IGBT, thus achieving accurate control of these semiconductor switching devices. Grid drivers have become an indispensable part of modern power electronic systems because of their high efficiency in signal conversion and stable driving performance.

FAQ about PMIC - Gate Drivers

  • 1. What is a gate driver?

    Circuit, gate signal enhancement, controller
    A gate driver is a circuit that is mainly used to enhance the gate signal of a field effect transistor (MOSFET) or an insulated gate bipolar transistor (IGBT) so that the controller can better control the operation of these semiconductor switches ，The gate driver controls the gate of the MOSFET or IGBT by converting the signal output by the controller into a high-voltage, high-current pulse, thereby improving the performance, reliability and service life of these devices.
    Working principle
    The gate driver is mainly composed of an input stage, a driver stage and an output stage:
    Input stage: responsible for receiving the signal output by the controller and converting it into a TTL or CMOS logic level.
    Driver stage: amplifies and converts the signal to generate a high-voltage, high-current pulse signal.
    Output stage: uses these pulse signals to control the gate of the MOSFET or IGBT.

  • 2. What is an active gate driver?

    An active gate driver is a circuit that is mainly used to enhance the gate signal of a field effect transistor (MOSFET) or an insulated gate bipolar transistor (IGBT) so that the controller can better control the operation of these semiconductor switches. It controls the gate of MOSFET or IGBT by converting the signal output by the controller into high-voltage, high-current pulses, thereby improving the performance, reliability and service life of these devices.

  • 3. What are the different types of gate drivers?

    There are mainly the following types of gate drivers:
    High-frequency high-voltage gate driver: This driver can drive two N-channel MOSFETs, supports a power supply voltage of up to 100V, has strong driving capabilities, is suitable for MOSFETs with high gate capacitance, and can reduce switching losses. It also has features such as undervoltage lockout and adaptive shoot-through protection.
    HL-type gate driver: The HL-type driver drives two N-channel MOSFETs in a half-bridge configuration and supports a power supply voltage of up to 140V. It has independent control outputs and strong anti-interference ability, and is suitable for application scenarios that require independent control of two MOSFETs. The HL type driver also has functions such as UVLO, TTL/CMOS compatible input, adjustable turn-on/off delay and shoot-through protection.
    Pulse transformer drive: This driver does not require a separate drive voltage, and applies a high voltage to the gate through a pulse transformer, which is suitable for half-bridge or full-bridge circuits. It uses a capacitor and pulse transformer in series to increase the switching speed, and quickly resets the pulse transformer through a Zener diode.
    Optocoupler and floating power supply drive: This driver uses an optocoupler to isolate the microcontroller and power transistor, and requires a separate floating power supply. The optocoupler output requires a separate power supply, which is suitable for high-side drive of half-bridge or full-bridge.
    Push-pull circuit: The push-pull circuit is suitable for situations where the drive current is insufficient. It provides sufficient drive current by alternating between two transistors, which is suitable for application scenarios that require high drive current.
    Half-bridge/full-bridge high-end drive: This driver applies a high voltage to the gate, which is suitable for half-bridge or full-bridge circuits. Since the source voltage of the high-end MOSFET changes, it needs to be powered independently and cannot share a ground with the low-end MOSFET.

We are a professional PCB manufacturer who offers comprehensive PCB manufacturing services including: professional Ceramic PCB HDI PCB Heavy Copper PCB High-TG PCB High Speed PCB High Frequency PCB Metal Core PCB PCB fabrication and PCB assembly, providing fast turnaround prototypes for high-end products.

• Prompt Responsiveness

• Guaranteed Quality

• Global Access

• Competitive Market Price

• One-Stop support services of supply chain

Jinftry, Your most trustworthy component supplier, welcome to send us the inquiry, thank you!

Do you have any questions about FAN7388MX ?
Feel free to contact us:

+86-755-28503874
+8615019224070, annies65, +8615118125813
568248857, 827259012, 316249462
+8615019224070, +8615118118839, +8615118125813
( Email first will be appreciative )
