LMK04131SQE/NOPB

National Semiconductor LMK04131SQE/NOPB

The picture is for reference only, please refer to the product specification

  • LMK04131SQE/NOPB
  • National Semiconductor
  • LMK04131 CLOCK JITTER CLEANER WI
  • Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
  • LMK04131SQE/NOPB Datasheet
  • 48-WFQFN Exposed Pad
  • Bulk
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 2933
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is LMK04131SQE/NOPB

National Semiconductor Part Number LMK04131SQE/NOPB（Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers）, developed and manufactured by National Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

LMK04131SQE/NOPB is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

LMK04131SQE/NOPB Specifications

  • Part NumberLMK04131SQE/NOPB
  • CategoryClock/Timing - Clock Generators, PLLs, Frequency Synthesizers
  • ManufacturerNational Semiconductor
  • DescriptionLMK04131 CLOCK JITTER CLEANER WI
  • PackageBulk
  • SeriesPLLatinum™
  • Type-
  • Voltage - Supply3.15V ~ 3.45V
  • Operating Temperature-40°C ~ 85°C
  • Mounting TypeSurface Mount
  • Package / Case48-WFQFN Exposed Pad
  • Supplier Device Package48-WQFN (7x7)
  • OutputLVCMOS, LVDS, 2VPECL, LVPECL
  • Frequency - Max1.08GHz
  • Number of Circuits1
  • InputLVCMOS, LVDS, LVPECL
  • PLLYes
  • Ratio - Input:Output2:6
  • Differential - Input:OutputYes/Yes
  • Divider/MultiplierYes/No

Application of LMK04131SQE/NOPB

Clock Generators are widely used in computer chips, digital circuits, radio communication, audio and video equipment and other electronic equipment. The clock signal generated by it is the basis for the normal operation of these devices, ensuring the stable transmission and processing of data. PLL (phase-locked Loop) is mainly used to detect and track the frequency and Phase of the input signal and convert it into a stable output signal. It can change the frequency of the input signal to achieve a specific purpose, such as signal synchronization, frequency conversion, etc. Frequency Synthesizers generate a series of high-precision frequency sources with a certain frequency interval through synthesis technology to provide the required frequency signals for various electronic devices. It is widely used in applications requiring accurate frequency control, such as radar, communications, electronic countermeasures and other fields.

LMK04131SQE/NOPB Datasheet

LMK04131SQE/NOPB Datasheet , Bulk,PLLatinum™,3.15V ~ 3.45V,-40°C ~ 85°C,Surface Mount,48-WFQFN Exposed Pad,48-WQFN (7x7),LVCMOS, LVDS, 2VPECL, LVPECL,1.08GHz,1,LVCMOS, LVDS, LVPECL,Yes,2:6,Yes/Yes,Yes/No

LMK04131SQE/NOPB Classification

Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers

Clock Generators are circuits or devices used to generate stable and precise pulses of electrical signals. The clock signal generated by it provides a unified time benchmark for various electronic devices, ensuring that the components of the device can synchronize operations and actions.PLL (Phase Locked Loop and phase-locked Loop) is a kind of circuit is used to control the frequency and Phase. It can convert the frequency and phase of an input signal into the frequency and phase of another output signal to realize the synchronization of frequency and phase. Frequency Synthesizers are devices that use one or more standard signals to generate a large number of discrete frequency signals through various technical approaches. It can realize precise control and adjustment of frequency to meet the needs of different application scenarios.
