MAX40024ANL+

Maxim Integrated MAX40024ANL+

The picture is for reference only, please refer to the product specification

  • MAX40024ANL+
  • Maxim Integrated
  • IC INST AMP PROG GAIN WLP
  • Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
  • MAX40024ANL+ Datasheet
  • 9-XFBGA, WLBGA
  • Tape & Reel (TR)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 18508
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is MAX40024ANL+

Maxim Integrated Part Number MAX40024ANL+（Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps）, developed and manufactured by Maxim Integrated, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

MAX40024ANL+ is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

MAX40024ANL+ Specifications

  • Part NumberMAX40024ANL+
  • CategoryLinear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
  • ManufacturerMaxim Integrated
  • DescriptionIC INST AMP PROG GAIN WLP
  • PackageTape & Reel (TR)
  • Series-
  • Operating Temperature-40°C ~ 125°C
  • Mounting TypeSurface Mount
  • Package / Case9-XFBGA, WLBGA
  • Supplier Device Package9-WLP (1.23x1.23)
  • Current - Supply17µA
  • Output TypeRail-to-Rail
  • Number of Circuits2
  • Voltage - Supply, Single/Dual (±)1.6V ~ 3.6V
  • Current - Output / Channel10 mA
  • -3db Bandwidth-
  • Amplifier TypeGeneral Purpose
  • Current - Input Bias0.1 pA
  • Voltage - Input Offset100 µV
  • Slew Rate0.02V/µs
  • Gain Bandwidth Product80 kHz

Application of MAX40024ANL+

Instrumentation Amplifier is commonly used in medical instruments, industrial sensors, precision measuring equipment and other applications. Its high common-mode rejection ratio and low noise characteristics make it possible to accurately capture and amplify weak signals in complex environments, improving the measurement accuracy. Operational Amplifier (Op-Amp) Operational amplifier is widely used in analog signal processing, signal generation, filter design, automatic control and other fields. Its flexibility and powerful computing power provide engineers with a broad design space, making the realization of complex circuits possible. Buffer Amplifier is widely used in audio amplification, video transmission, data acquisition and other systems, effectively improving the stability and reliability of signal transmission.

MAX40024ANL+ Datasheet

MAX40024ANL+ Datasheet , Tape & Reel (TR),-40°C ~ 125°C,Surface Mount,9-XFBGA, WLBGA,9-WLP (1.23x1.23),17µA,Rail-to-Rail,2,1.6V ~ 3.6V,10 mA,General Purpose,0.1 pA,100 µV,0.02V/µs,80 kHz

MAX40024ANL+ Classification

Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

Instrumentation amplifiers are designed for high precision measurements. It can effectively amplify weak differential signals (that is, two similar but slightly different signals), while suppressing common mode noise (that is, noise shared by two signals), thus ensuring the purity and accuracy of the signal.Operational Amplifier (Op-Amp) is a high-gain DC amplifier with differential input and single-ended output. Operational amplifiers can not only be used as amplifiers, but also realize mathematical operations such as addition, subtraction, integration, and differentiation through external circuit configuration.Buffer Amplifier is a special amplifier configuration that aims to keep the voltage of the input signal constant while providing enough driving capacity to support the load. It is usually implemented based on an operational amplifier.

FAQ about Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

  • 1. What is the difference between an instrumentation amplifier and an operational amplifier?

    Instrumentation amplifiers integrate multi-stage operational amplifiers for precise amplification of differential signals, while operational amplifiers are more versatile and can perform a wide range of analog signal processing tasks. Instrumentation amplifiers have higher input impedance and better common mode rejection.

  • 2. How to achieve high accuracy and low drift in instrumentation amplifiers?

    Select an amplifier with low bias current, low offset voltage, and low noise, and reduce the effect of temperature drift on accuracy through a stable power supply and proper temperature compensation circuit design.

  • 3. What is the effect of the op amp's out-of-range voltage on accuracy?

    An out-of-phase voltage is the difference in voltage at which the output is not zero when the signal at the input is zero. A large out-of-phase voltage reduces the accuracy of a system, especially in high-gain applications, and selecting an op amp with a low out-of-phase voltage can improve accuracy.
