Texas Instruments TPD2E001DRLR
The picture is for reference only, please refer to the product specification
- TPD2E001DRLR
- Texas Instruments
- TVS DIODE 5.5VWM 100VC SOT5
- TVS - Diodes
- TPD2E001DRLR Datasheet
- SOT-553
- SOT-553
-
Lead free / RoHS Compliant - 710
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is TPD2E001DRLR
Texas Instruments Part Number TPD2E001DRLR（TVS - Diodes）, developed and manufactured by Texas Instruments, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
TPD2E001DRLR is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
TPD2E001DRLR Specifications
- Part NumberTPD2E001DRLR
- CategoryTVS - Diodes
- ManufacturerTexas Instruments
- DescriptionTVS DIODE 5.5VWM 100VC SOT5
- PackageSOT-553
- Series-
- TypeSteering (Rail to Rail)
- Operating Temperature-40°C ~ 85°C (TA)
- Mounting TypeSurface Mount
- Package / CaseSOT-553
- Supplier Device PackageSOT-5
- ApplicationsEthernet
- Unidirectional Channels2
- Voltage - Reverse Standoff (Typ)5.5V (Max)
- Voltage - Breakdown (Min)11V
- Power Line ProtectionYes
Application of TPD2E001DRLR
TPD2E001DRLR Datasheet
TPD2E001DRLR Datasheet , SOT-553,Steering (Rail to Rail),-40°C ~ 85°C (TA),Surface Mount,SOT-553,SOT-5,Ethernet,2,5.5V (Max),11V,Yes
TPD2E001DRLR Classification
TVS - Diodes
FAQ about TVS - Diodes
-
1. What does a TVS diode do?
The main function of TVS diodes (Transient Voltage Suppression Diodes) is to protect electronic equipment from voltage spikes and surge voltages. When the two poles of the TVS diode are impacted by reverse transient high energy, it can change the high impedance between the two poles into low impedance within 10^-12 seconds, while absorbing surge power up to several kilowatts, causing the gap between the two poles to The voltage is clamped to a safe value, thereby effectively protecting precision components in electronic circuits.
The specific working principle of TVS diodes is as follows:
Absorb surge power: TVS diodes can, under reverse application conditions, when subjected to a high-energy large pulse, their working impedance immediately drops to a lower conduction state, allowing large current to pass while clamping the voltage at predetermined level. Its response time is only 10^-12 seconds.
Protection circuit: TVS diodes are used in parallel with the protected circuit. When the circuit is working normally, the TVS diode is in a high impedance state and does not affect the circuit; when there is a surge voltage impact, the TVS diode conducts quickly, absorbs the surge energy, and protects the subsequent circuit.
-
2. Are TVS diodes and Zener diodes the same?
TVS diodes and Zener diodes have significant differences in functionality and characteristics, so they are not identical.
Definition and purpose
Zener diode: Zener diode is a diode that uses a PN junction for reverse breakdown. It is mainly used to ensure voltage stability. It has a high resistance state before the reverse breakdown voltage and is in a low resistance state after exceeding this critical point. It is widely used in various voltage stabilizing circuits and reference voltage components.
TVS Diode: TVS diode (Transient Suppression Diode) has surge absorption capability and is mainly used to protect circuits from damage caused by transient high voltages such as surges and electrostatic discharge (ESD). It can absorb a large amount of instantaneous current and voltage in a short period of time, protecting the subsequent equipment or circuits from damage.
-
3. What is the difference between TVS and ESD diodes?
The main difference between TVS diodes and ESD diodes is their working principle, application scenarios and characteristics.
Working principle and application scenarios
TVS diodes (Transient Voltage Suppressors): TVS diodes are mainly used to suppress transient voltages and prevent components in the circuit from being damaged by surge voltages. When the two poles of the TVS diode are impacted by reverse transient high energy, it can change the high impedance to low impedance in a very short time, absorb the surge power, and protect the precision components in the circuit1. TVS diodes are suitable for protection against various surge pulses, such as lightning strikes, large-capacity load switching, etc.
ESD diode (Electro-Static discharge): ESD diode is mainly used to prevent static electricity and prevent damage to electronic equipment caused by electrostatic discharge. ESD diodes have low capacitance values, typically between 1 and 3.5 picofarad (PF), to accommodate the rapid changes in electrostatic discharge. ESD diodes are suitable for board-level protection, especially in high-speed USB and I/O interfaces, which have higher requirements for electrostatic discharge.
